Solder Paste Printer
Semi Automatic Solder Paste Printer ASP-300
Description
This unit is used for printing the solder paste onto the bare PCB under the stencil.
High positional accuracy, repeated positioning accuracy ±0.01mm; printing accuracy 0.025mm.
Support glue printing, automatic control improves production efficiency, quality control and saves production cost.
Automatic PCB calibration, squeegee pressure adjustable, automatic printing and stencil cleaning.
Programmable motor controls separation speed and distance among squeegee, stencil and substrate, to realize multi-method separation.
Features
1. Modular design
2. Applies to high precision, printing precise is up to 0.2mm IC.
3. PLC + touch screen display, more stable and easier to operate.
4. Combined with a fixed groove printing platen and PIN, easy installation and adjustment,for single, double side printing.
5. Scrape angle, pressure, travel length can be adjusted, flexible.
6. The printing plate can be fine tuning X.Y axis, higher precise.
7. Automatic counting function, easy to statistics and arrange production.
8. Automatic alarm of cleaning the stencil, convenient for cleaning stencil in time and ensure the printing quality.
| Model | ASP-300 | ASP-1200 | ASP-1500 |
| Dimension | 900*900*1650 | 1750*900*1650mm | 2000*900*1650mm |
| Platform size (mm) | 320*500 | 320*1250 | 320*1550 |
| PCB size (mm) | Max 350*300mm | Max 1200*300 | Max 1500*300 |
| Stencil size (mm) | 370*470 | 370*1300 | 370*1600 |
| Printing speed (mm/min) | 0-8000 | 0-8000 | 0-8000 |
| PCB thickness (mm) | 0.2-2.0 | 0.2-2.0 | 0.2-2.0 |
| Power supply | AC220V 50Hz | AC220V 50Hz | AC220V 50Hz |
| Platform height (mm) | 850～900 | 850～900 | 850～900 |
| Weight (kg) | 250 | 320 | 380 |
